Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: coreman
  • Model Number: P6p8p12p10p20p25-OD-SC-01
  • Usage: indoor or outdoor ,semi-outdoor
  • Tube Chip Color: RGB
  • Display Function: video,graphices,messages ,pictures
  • Pixels: 3mm/4MM/5MM/6MM/7.62MM/8MM/10MM/12MM/14mm/16mm/25mm/31.25mm.40mm
  • Screen Dimension: module size: 128*256mm
  • application place: international football game/ world cup/NBAbasketball contest
  • LED chip: epistarcree/nichia
  • controller way: linsn. DBstar ,Novastar
  • power supply: meanwell
  • Input signal: S-video, VGA, PGB, Composite Video, SDI etc
  • screen parts: light case /video processor
  • broadcast: from video camera , live TV through video processor
  • Display fuction: video,graphic,animation,text ,messages ,pictures.photo etc.
  • cabinet material: aluminum or steel optional
  • display type: indoor/outdoor SMD 3IN1 or DIP real/virtual indoor/outdoor

Packaging & Delivery

Packaging Details 1. wooden case
2. flight case
Delivery Time 4-12working days
Product Description



Stadium LED Screen Display





Item nameP10P12P16P20P25
Module size(W*H)160*160mm192x192mm128x256 mm160x320 mm200x200 mm
pixels Density 10000 dots/sqm6944 dots/sqm3906 dots/sqm2500 dots/sqm1600 dots/sqm
Pixel configuration1R1G1B2R1G1B2R1G1B2R1G1B2R1G1B
Pixel resolution16*16 dots16*16 dots8*16 dots8*16 dots16*16 dots
Brightness≥7000 cd/sqm≥6500 cd/sqm≥6000 cd/sqm≥5500 cd/sqm≥5000 cd/sqm
Drive type1/4 Scan1/4 scanstaticstaticstatic
Power supply5V/60A*6 pcs
thermal dischargefan*2/4 pcs
Best viewing angle120°(H) /90°(V)
Temperaturestorage: - 35℃~+ 85℃
working: '- 20℃~+ 65℃
Operation humidity≤90 ~ 95%
Thickness18cm
Working voltageAC220V ± 10%
Aver Consumption400-600 w/sqm
Max. Consumption≤1000 w/sqm
Operating systemWIN 7/8/98/2000/NT/XP
control methodSynchronization
Driving deviceConstant Current
Refresh frequency≥480Hz/s
Grey scale/colors256 levels of each color(R/G/B)/ 16.7M colors
Control systemDVI display card + full color controller card
MTBF≥10, 000 hours
Life span≥70, 000 hours
FlatnessTolerance of pixel pitch≤0.3mm

Tolerance of modules between ≤1.5mm





  Features :





1. The cabinets have uniquely designed bracing bar with angle-adjustable function so that our football perimeter LED screens can be placed on the football court accordingly with inclination angle adjusted between 75°~90°, ensuring all the audiences from different viewing angles can see the display content clearly.







2. Perimeter LED screens are attached with soft module veil and soft material on the top of the cabinets, so that the LED lamps can be protected and athletes can also be protected from harm caused by collision.







3. With efficient Optical Fiber data transfer system, the signal delay problem caused by long distance data transfer on the football court has been solved effectively, ensuring the uniformity of images displayed.







4. With hot-standby function of two cable networks, two computers control the same one LED screen independently. Once the working computer crashes, the other hot standby computer would take over the control system immediately, enduring LED screens’ consistent performance.







5. With high waterproof level IP65, the LED screens can be operated consistently without any interrupt in the raining days.







6. Equipped with unique program for football LED screens, operators can easily manage the match scores display, live video playback, advertisement display and displayed content list edited with program.







7. With 4800Hz high refreshing rate, the high demand of dynamic camera shooting can be easily satisfied and the flicker phenomenon in camera shooting can be effectively avoided.









Product Picture




Successful Project








Package

                               Wooden case                                                                                          flight case
