Quick Details

  • Place of Origin: China (Mainland)
  • Brand Name: Coreman
  • Model Number: SMD-Indoor/Outdoor-RGB-P6 / P6.67 / P8 / P10
  • Usage: Indoor/outdoor
  • Tube Chip Color: Full Color
  • Display Function: Video
  • Pixels: p6 / p6.67 / p8/ p10
  • Screen Dimension: Customized
  • IP level: IP32~IP65
  • Life span: 11 years
  • Color: 16777216
  • Grey level: 16 bit per color
  • Led chip: Nicha,Cree, Epistar,Silan, Opto
  • Driving IC: MBI5024,MBI5026,MBI5030,MBI5034
  • Warranty: 3~5 years
  • High refresh rate: >2000HZ
  • LED lamp: black pearl led
  • Cabinet: Die-castiing,extruded aluminium cabinet

Packaging & Delivery

Packaging Details 1.Pearl wood +Cartoon case
2.Pearl wood+Wooden case
3.Pearl wood+Flight case
Delivery Time 3-12 days

&Technical parameter



---Indoor SMD parameter



Item No.P1.875P2.5P3P4
ClassificationFull colorFull colorFull colorFull color
Pixel pitch1.875mm2.5mm3mm4mm
Size of module (mm*mm)240*240160*80192*96128*128/256*128
Pixel density28000 dots/m2160000 dots/m2111111 dots/m262500 dots/m2
Pixel composition1R1G1B1R1G1B1R1G1B1R1G1B
LED encapsulationCOB 3in1COB 3in1SMD2121SMD2121
Resolution of module128*12864*3264*3232*32/64*32
Best viewing distance0.5m1m2m2m
Best viewing angle (Horizontal/Vertical)140°/140°140°/140°140°/140°140°/140°
Max power consumption1300W/m21200 W/m21200 W/m21000 W/m2
AVG power consumption400~550 W/m2400~500 W/m2400~500 W/m2350~500 W/m2
Size of standard cabinet(mm)480*480480*480576*576512*512
Resolution of standard cabinet256*256192*192192*192128*128
Weight of standard cabinet10kg10kg15kg12kg
Driving method1/32 Scan1/16 Scan1/32 Scan1/16 Scan
Frame frequency60Hz/s60Hz/s60Hz/s60Hz/s
Refresh rate2000HZ1500HZ1500HZ1500HZ
White balance brightness800cd/m21500cd/m21800cd/m2≥1300cd/m2
Working /Storage environment temperatureWorking: —20°C~55°C   Storage:  —40°C~65°C
Operating ambient humidityWorking:  10%--95% HR   Storage: 10%--95% HR
IP gradeIP20~IP54
Working voltageAC 220±10% or 110±10%
Grey scale16 bits per color
Brightness adjustment256 levels of each color (RGB) can be adjusted manually
Signal input   RF, S-Video, RGB, RGBHV, YUV, YC.ect
Control systemPCTV non-linear editing card+ DVI display card+ main controller card+ optical fibre transmission ( optional)
MTBF≥5000 hours
Life span≥100000 hours
Malfunction dot rateless than0.0001
Transmission distanceLAN cable less than100m; Optic fiber transmission: MMF less than 500m, SMF less than 20km
Refresh rate can be higher by using more receivers: other parameter can be changed according to different application.







----Outdoor SMD parameter



Item No.P6P6.67P8P10
ClassificationFull colorFull colorFull colorFull color
Pixel pitch6mm6.678mm10mm
Size of module (mm*mm)192*192320*160320*160320*160
Pixel density27777 dots/m225600dots/m215625 dots/m210000dots/m2
Pixel composition1R1G1B1R1G1B1R1G1B1R1G1B
LED encapsulationSMD3535SMD3535SMD3535SMD3535
Resolution of module32*3248*3240*2032*16
Best viewing distance6m6m8mm10m
Best viewing angle (Horizontal/Vertical)140°/140°140°/140°140°/140°140°/140°
Max power consumption1100W/m2950W/m2800W/m2900W/m2
AVG power consumption400~450W/m2380~450W/m2300~400W/m2300~400W/m2
Size of standard cabinet(mm)576*576640*640640*640640*640
Resolution of standard cabinet96*9696*9680*8064*64
Weight of standard cabinet10kg
(Aluminium Die Casting)
12kg
(Aluminium Die Casting)
12kg
(Aluminium thin cabinet)
12kg
(Aluminium thin cabinet)
Driving method1/4 Scan1/6 Scan1/4Scan1/2Scan
Frame frequency60Hz/s60Hz/s60Hz/s60Hz/s
Refresh rate≥2000HZ≥2000HZ≥2000HZ≥2000HZ
White balance brightness≥7200cd/m2≥7200cd/m2≥6500cd/m2≥6500cd/m2
Working /Storage environment temperatureWorking: —30°C~55°C   Storage:  —40°C~65°C
Operating ambient humidityWorking:  10%--95% HR   Storage: 10%--90% HR
IP grade Front :IP65  Back :IP65
Working voltageAC 220±10% or 110±10%
Grey scale16 bits per color
Brightness adjustment256 levels of each color (RGB) can be adjusted manually
Signal input   RF, S-Video, RGB, RGBHV, YUV, YC.ect
Control systemPCTV non-linear editing card+ DVI display card+ main controller card+ optical fibre transmission ( optional)
MTBF≥10000 hours
Life span≥100000 hours
Malfunction dot rateless than0.0001
Transmission distanceLAN cable less than100m; Optic fiber transmission: MMF less than 500m, SMF less than 20km
Refresh rate can be higher by using more receivers: other parameter can be changed according to different application.



&& Feature



1. First-class LED chip. Supplied by Nichia of Japan & other high strictly selected LED chip to ensure the long lifetime and high brightness



2. High Contrast ratio: above 2000:1 .very high level to ensure a vivid image of our LED display screen system



3. Clear vivid image quality. more than 140 degree in horizontal and vertical to ensure you attract more audience to get short ROI of your LED display screen's investment



4.High definition. from p3 to p10, led display with high resolution to keep good video effect



5.Thin cabinet :we have die-case cabinet and new design cabinet for your choose, less than 10kg/pcs



6. Seamless stitching: With a special connector design it is easy to reduce gaps while installing, creating a perfect display.





&&Other smd product



indoor smd

-----p3: size:    192mm*96mm/96mm*96mm

-----p4: size:    128mm*128mm

-----p5: size:    160mm*160mm

-----p6: size:     192mm*96mm

-----p7.62: size: 244mm*122mm

-----p8: size:      256mmm*128mm

-----p10: size:    320mm*160mm



outdoor smd

-----p6: size: 192mm*96mm

-----p8: size: 256mm*128mm

-----p10: size: 320mm*160mm

-----p16: size: 256mm*128mm



&&Module Picture



----Indoor SMD led module







 -----Outdoor Waterproof  SMD led module





&&Light weight cabinet for your choose



----Different cabient: easy install and lightweight



















&& Testing picture







-----Installation







&& Signal draw





&&Look,how we do led display



If you like our products, pls contact us any time ,

coreman make your life easy , enjoy your wonderfull life anywhere
